Products
Particle Board
PRODUCT DETAIL
Particle Board is highly regarded for its flawless composition and consistent density, enabling clean cutting, routing, shaping, and drilling. It effectively retains intricate details while minimizing waste and tool wear.
Common Applications
• Cabinetry
• Furniture
• Shelving
• Surface for veneers
• Wall paneling
• Door Core*
*Door core panel thickness starts from 1-1/8” to 1-3/4”
Specifications
Dimensions
|
|
Imperial |
Metric |
|
Widths |
4-7 ft |
1220-2135mm |
|
Lengths |
up to 16 ft |
up to 4880mm |
|
Thicknesses |
3/8-1 in |
9mm-25mm |
Details
|
|
Imperial |
Metric |
|
Moisture Content |
5.80% |
5.80% |
|
Internal Bond |
61 psi |
0.42 Mpa |
|
Modulus of Rupture/MOR |
1800 psi |
12.4 Mpa |
|
Modulus of Elasticity/MOE |
380000 |
2660 Mpa |
|
Screw Holding–Face |
279 lbs |
1240 N |
|
Screw Holding–Edge |
189 lbs |
840 N |
|
Formaldehyde Emissions Limit |
0.039 ppm |
0.048mg/m³ |
|
Moisture Content |
5.80% |
5.80% |
Values presented are averages specific to 3/4" panels, the physical properties may differ depending on thickness
Standards & Certifications
|
Formaldehyde Release Rating |
Carb P2&EPA、E1、E0、ENF、F**** |
Our Particle Board is tested and certified to meet or exceed the following standards and certifications.
Formaldehyde Emissions Regulations-Third party certified (TPC-1) to meet the requirements of: EPA Formaldehyde Emission Regulation, TSCA Title VI.
Forest Stewardship Council® Scientific Certifications Systems Certified (FSC-STD-40-004 V3-0;FSC-STD-40-007 V2-0;FSC-STD-50-001 V2-0).
We can also produce boards of different grades according to your requirements to meet different formaldehyde emission standards.
